NT-OUT General model (big)
Detailed Product Description
Asphalt resin filled and vacuum potted.
Patented magnetic core at low consumption.
Metal box and coated power.
User Friendly-Adapts to most grounding situations.
Features:
-Traditional coil and core transformer
-Compact size and light weight
-Asphalt resin filled and vacuum potted
-High reliability and long life
-Environmental Specifications
-Cooling: Convection
-Relative humidity: 5% to 95%
-Design patent NO.:ZL02343650.6.
Specification:
220V 50Hz 30mA/60mA Series Transformer(230V,240V,60Hz is optional)
|
Vendor's Model Name
|
Input Voltage(V)
|
Input Current(A)
|
Frequency(Hz)
|
Output Voltage(KV)
|
Output Current(mA)
|
Watts (VA)
|
|
NT-1530-OUT(220)
|
220
|
2.1
|
50
|
15
|
30
|
450
|
|
NT-1230-OUT(220)
|
220
|
1.7
|
50
|
12
|
30
|
360
|
|
NT-0930-OUT(220)
|
220
|
1.3
|
50
|
9
|
30
|
270
|
|
NT-7530-OUT(220)
|
220
|
1.1
|
50
|
7.5
|
30
|
225
|
|
NT-1560-OUT(220)
|
220
|
4.1
|
50
|
15
|
60
|
900
|
|
NT-1260-OUT(220)
|
220
|
3.3
|
50
|
12
|
60
|
720
|
Remark: Critical specification should be confirmed before placement of order, for further information ,please contact with us.
